    Post 06 jeep project

    Post by david on Fri Jun 04, 2010 12:42 pm

    First topic message reminder :

    I started off with a brand new 2006 jeep wrangler that I picked up in Feb. of 06. For the power train it has a 4.0 inline 6, a 4 speed automatic transmission, dana 30 front, and at the time a dana 35 rear end.
    My jeep when it was 2 day old

    Warn front bumper, d-rings, warn 9000lb winch, and hi lift jack

    Warn rock sliders

    Custom rear bumper and tire carrier, with ammo box holder

    Installed a 4” rough country lift, and 33” tire with 15x8 MT wheel locks
    avatar
    david

    Join Date : 2008-12-01
    Number of posts : 286

    Model : Wrangler TJ

    Post Re: 06 jeep project

    Post by david on Thu Dec 16, 2010 9:22 pm

    Started the tar down of my front differential a few days ago for my gear swop, but did not get to far an had to stop. Today I finished pulling the axels and differential out of my front dana 30

    Left side axel



    Right side axle pulled out a little



    ARB air locker with the 4:10 ring gear still bolted to it soon to have a 4:88 ring gear



    Empty dana 30 diff housing

    avatar
    shortbusjeep

    Join Date : 2010-12-10
    Number of posts : 29

    Model : Truggy

    Post Re: 06 jeep project

    Post by shortbusjeep on Thu Dec 16, 2010 11:43 pm

    wow your gonna set your own gears up? cool wish i had just had you help me do mine for the truck.
    avatar
    Yuma 4X4
    YUMA 4X4 FOUNDER

    Join Date : 2008-11-28
    Number of posts : 3702

    Post Re: 06 jeep project

    Post by Yuma 4X4 on Fri Dec 17, 2010 5:14 am

    shortbusjeep wrote:wow your gonna set your own gears up? cool wish i had just had you help me do mine for the truck.

    Toyotas are easier than Dana axles.

    I paid someone to do them the first time, but did my own the second and 3rd times.

    I made my own carrier bearing tool too.
    avatar
    shortbusjeep

    Join Date : 2010-12-10
    Number of posts : 29

    Model : Truggy

    Post Re: 06 jeep project

    Post by shortbusjeep on Fri Dec 17, 2010 12:23 pm

    i always wanted to try but figured why chance it. that gets alot of use and when it fails your getting towed home.
    avatar
    david

    Join Date : 2008-12-01
    Number of posts : 286

    Model : Wrangler TJ

    Post Re: 06 jeep project

    Post by david on Mon Dec 20, 2010 9:43 pm

    shortbusjeep wrote:wow your gonna set your own gears up? cool wish i had just had you help me do mine for the truck.

    Like Chris said Toyota differentials are easier, because you can set the preload and gear back lash up on the bench, and then bolt it into the axel housing. I have seen a Toyota axle set up about 6 year ago when I was still in school and it did not look too hard. This was my first gear swap I have done, had to pull the carrier out six times before I got the back lash set that I was happy with. I like to thing I am some what mechanical inclined, due to turning wrench on heavy equipment for the last 5 years.

    Being into the rock crawling thing I like to know as much as I can about my rig so I can fix it on the trail if possible and not have to depend on other to fix my rig. Been in that situation were I was Broke an had know idea how to get it out. I felt bad at the end of the day because he did almost all the work to get my rig out of the desert.

    avatar
    david

    Join Date : 2008-12-01
    Number of posts : 286

    Model : Wrangler TJ

    Post Re: 06 jeep project

    Post by david on Mon Dec 20, 2010 9:48 pm

    Last Saturday I got the gears set up and all bolted into the diff. today I put the axles in and installed the new brakes. Ill get some pic up later of the gears being set up and the new brakes
    avatar
    david

    Join Date : 2008-12-01
    Number of posts : 286

    Model : Wrangler TJ

    Post Re: 06 jeep project

    Post by david on Thu Dec 23, 2010 5:40 pm

    Hear are the pics of the gears going back in. only had to pull the carrier out 6 time before the back lash was right



    axels back in



    Old brake shoes, not much left



    After a trip to Napa



    Started on the gears in the rear end to day, pulled the brakes off the drive line out and pulled the axel. Started to pull the carrier when I was reminded of a Christmas part I have to go to



    avatar
    david

    Join Date : 2008-12-01
    Number of posts : 286

    Model : Wrangler TJ

    Post Re: 06 jeep project

    Post by david on Mon Dec 05, 2011 11:03 pm

    wow it has been some time since i have updated this

    9" procomp HID off road light and home made light bar



    1/4" plate steel diff cover



    warn rear diff guard



    roof rack i built last year the day before i left on a 3 day camping trip with the steel i had around the house the basket i got from a friend. i removed it right after the two back to back trips.





    i have also installed an ORFab roll cage, sprayed the roll cage with bed liner,
    avatar
    Perry

    Join Date : 2008-12-02
    Number of posts : 1081

    Model : Cherokee

    Post Re: 06 jeep project

    Post by Perry on Wed Dec 07, 2011 11:34 am

    I am really impressed with your Jeep now!! It rocks and rolls...
    avatar
    david

    Join Date : 2008-12-01
    Number of posts : 286

    Model : Wrangler TJ

    Post Re: 06 jeep project

    Post by david on Sun Dec 25, 2011 11:27 pm

    a few upgrades i did back in October and November

    rough countery high clearance t-case skid, 1" JKS body life and a new set of 35" mickey thompson ttc baja claws

    avatar
    Rubiking 02

    Join Date : 2011-09-02
    Number of posts : 260

    Model : Wrangler TJ

    Post Re: 06 jeep project

    Post by Rubiking 02 on Tue Dec 27, 2011 10:09 am

    Nice Rough Country .........Tummy Tuck David
